AB YACHT 80

MAIN CHARACTERISTICS:
Type of Vessel: Motor Yacht
Shipbuilder: AB YACHTS, Next Yacht Group
Class & Certification: R.I.Na – C ✠ HULL ● MACH Y – Unrestricted Navigation
(Pleasure Yacht) – CE – Certficate – Category A
Structure: Fiberglass with carbon fiber reinforcements (to ensure lightness and comfort)

ASKING PRICE € 9,100,000

Dimensions:
Length Overall (LOA): 25.40 m
Hull Length (LH): 23.97 m
Maximum Beam: 6.50 m
Draught: 1,35 m

Approx Displacement (Full):
– 80 Tonnes

Propulsion & Main Engines:
– [3] MAN- V12-2000 Hp (1471Kw- 2300RPM)
– [2] MJP steerable waterjets + [1] MJP central booster

Gensets:
– [2] KOHLER 32kW each – 240V, Single –Phase – 60hz

Air Conditioning:
– FRIGOMAR 140.000 BTU

Bow thruster:
Electric thruster, SIDE POWER 240V

Voltage:
– 240V bi-phase, 60 Hz (USA)

Maximum Speed:
– 54 knots

Cruising Speed:
– 49 knots

Fuel Capacity:
– 9.000 litres ca.

Water Capacity:
– 2.000 litres

ACCOMMODATIONS:

Owner’s Cabin and Guests:
– [1] Suite Owner (full beam) on the Lower deck
– [1] Vip Cabins on the Lower deck
– [2] Guest Cabins with two bed each on the Lower Deck

Crew:
– [1] Crew Cabin with two beds

Bathrooms:
– [4] Guests bathroom
– [1] Day-head on the Main Deck
– [1] Crew Bathroom

HOUSEHOLD APPLIANCES:

Galley:
– [1] BORA Extraction hood
– [1] BORA Cooking top (composed by: n.1 Induction top 32cm, n.1 Teppan Yaki)
– [1] MIELE Oven 60 cm
– [1] MIELE Dishwasher 45 cm
– [1] Sink 40×40 cm
– [1] LIEBHERR Fridge/Freezer in column height 177 cm

Crew:
– [1] MIELE Washer/ Dryer GE Appliances

ELECTRONIC NAVIGATION EQUIPMENT:

On the Wheelhouse:
– [1] SIMRAD monitor 24″ + [2] monitors 19″ (on one of the 19“ Monitors it will be visible the
Monitoring System)
– SIMRAD Radar Halo 24
– SIMRAD Echosounder (graphic)
– AIRMAR transducer (log,speed,temp) data only
– SIMRAD Autopilot
– SIMRAD VHF
– [2] SIMRAD GPS
– SIMRAD AIS [optional]
– AIRMAR Weather Station [optional]

Fly bridge:
Mini-station on Sundeck: [optional]
▪ VHF SIMRAD remote handset [optional]
▪ Multifunctional colour display 4.1″ mod.IS42 (for data only) [optional]

AUDIO – VIDEO SYSTEM:
Owner’s Cabin:
– [1] SAMSUNG Smart TV Led 43’’
– [1] HDMI&USB – Wall Plate
– Streaming: Netflix e Disney+ via Smart TV. Spotify via Bluesound amplifier
– [2] Dynaudio P4-W65 speaker 6,5” rectangular
– [1] APPLE iPad mini 6 64GB Wi-Fi (Crestron configured)

Guest Cabins (x2) Equipment list per Cabin:
– [1] SAMSUNG Smart TV 32” Full HD for the Guest Cabin Port side
– [1] SAMSUNG Smart TV 24” Full HD for the Guest Cabin Starboard side
– [1] HDMI&USB – Wall Plate
– Streaming: Netflix e Disney+ via Smart TV. Spotify via Bluesound amplifier
– [2] Dynaudio P4-W65 speaker 6,5” rectangular
– [1] APPLE iPad mini 6 64GB Wi-Fi (Crestron configured)
– TV Receiver/ Decoder (Owner’s supply)

Vip Cabin:
– [1] SAMSUNG Smart TV 32” Full HD
– [1] HDMI&USB – Wall Plate
– Streaming: Netflix e Disney+ via Smart TV. Spotify via Bluesound amplifier
– [2] Dynaudio P4-W65 speaker 6,5” rectangular
– [1] APPLE iPad mini 6 64GB Wi-Fi (Crestron configured)

Main Salon:
– [1] SAMSUNG Smart TV 65’’ 4K
– [1] HDMI&USB – Wall Plate
– Streaming: Netflix e Disney+ via Smart TV. Spotify via Bluesound amplifier
– [5] Dynaudio P4-W65 speaker 6,5” rectangular
– [1] JL-Audio Home subwoofer 8
– [1] Apple iPad Mini 6 64GB Wi-Fi (Crestron configured)
– TV Receiver/ Decoder (Owner’s supply)

External Area (for Aft Deck, Bow and Fly bridge):
– JL-Audio waterproof Speakers 770 Luxe 7.7”- 4x Aft Deck, 2x Bow, 4x Sun Deck
– [1] Amplifier, with 2 channels for each area, including Airplay 2 and Spotify Connect streaming

Party Mode:
Party mode option will replicate settings of Main Salon and will merge areas of: Aft Deck, Bow and Flybridge

OPTIONAL LIST INCLUDED:
– Class R.I.Na. – C ✠ HULL • MACH Y – Unrestricted Navigation (Pleasure)
– Seamless Transfer: “No-Power-blackouts” smart technology in order to avoid the blackouts from
witching the genset power onto the shore power supply, and vice versa
– Gyroscopic stabilizers Seakeeper mod.18: working at anchor (“zero speed”) and in navigation
(“underway”)
– AIS + Weather Station
– Genset’s Parallel system
– Monitoring System
– Monitoring system redundancy, in Crew Area
– Aft Third Control Station
– Stern garage and haulage/launching system for tender/jet ski
– N.4 underwater lights on the transom, white colour
– Watermaker IDROMAR 180 Lt/hr instead of 130 Lt/hr
– Electric blind curtains in the Salon
– Electric blind curtains in the Lower Deck’s accommodations (Owner- Vip – Guest’s Cabin)
– Electric black-out rollers in the Master Cabin and in the Lower Deck’s accommodations
(Owner- Vip – Guest’s Cabin)
– Portholes sensors
– Outdoor Awnings on aft and bow complete with Carbon fibre poles and micro-perforated technical
fabric tent
– Air Conditioning Tropicalized 140.000 Btu/h, instead of standard 100.000 Btu/h
– Predisposition only for night vision camera
– Day-head in the Salon
– Mini Pilot station on the Sundeck
– Stainless steel Rub-Rail
– Frequency Converter 40 Kva
– [1] External table with up/down electric mechanism in the aft cockpit
– Dark or Metallic paint
– Teak on Sun Deck
– Plug-in carbonfibre shower in the Beach Area
– Additional Boiler 45 lt
– Air Compressor, with 3 connection points (n.1 in the aft area, n.1 in the bow area, n.1 in the E.R.)
– Glass side corridors handrail, with polished stainless steel perimetral frame

IT and Wi-Fi:
• [1] Peplink MAX HD1 Dome Pro 5G router with 4/5G and Wi-Fi built-in antennas
• [1] Ubiquiti Dream Machine Pro Router wireless controller, Firewall
• [1] Ubiquiti with 48 POE switch for all physical ethernet connections
• [4] Ubiquiti Access Point UniFi 6 Long-Range 4800 Mbit/s PoE (distributed across all decks)
• Cable Predisposition Only, for Starlink Maritime Antenna

CCTV system:
▪ [3] Lilin Z5R6422XR 2 Megapixel outdoor dome with IR led Camera
▪ [1] Lilin PZD6422EX mini PTZ (no IR) 2M pixel in Engine Room
▪ [1] Lilin NVR6104E 4ch PoE standalone network video recorder
